sitespeed.io 12.1 and Browsertime 8.1

In the new version of sitespeed.io, me (Peter) teamed up with Chris Adams of the Green Web Foundation and we created a sustainable web plugin that makes it possible to calculate estimated carbon emission for a page.

This release also makes it easier to run different WebDriver versions, easier support for MS Edge and video and visual metrics support on OS X!

Read all about the new things here:

The sustainable web plugin #

Sustainable web logo

We know using the internet means using electricity to power servers. And because most of that electricity comes from burning fossil fuels, it means every byte sent has a cost in carbon as well as power. The sustainable web plugin combines the latest in peer reviewed science and open data from the Green Web Foundation to help you build greener, more sustainable websites and applications!

We work out how much energy it takes to serve a site, then work out how much CO2 is emitted to generate the power needed that electricity, based on what information we have about where the power comes from.

Chris Adams has written down more details how we do the calculations.

How to use it #

Enable the plugin by adding --sustainable.enable:

docker run --rm -v "$(pwd)":/sitespeed.io sitespeedio/sitespeed.io:13.3.0 https://www.sitespeed.io/ --sustainable.enable

The result #

All data is produced under the new tab called Sustainable Web.

Sustainable web tab

The plugin will use the transfer size of every asset and the domain (to know if the server run on green energy) and estimate the total amount of carbon emission for one page view.

First you will see the amount of estimated carbon emission for one page view.

Estimated carbon emission per page view

But you can also add --sustainable.pageViews to your run and you will get the estimated carbon for that amount of page views. If you run it with --sustainable.pageViews 100000 you will get something like this:

Total carbon emission

Both the amount per page view and the total among will be automatically sent to Graphite/InfluxDB.

We also categorise content per first/third party (with the --firstParty switch). You can see that for the site in this example the estimated carbon emission from third parties are over 79% of the total emission :(

The next cut is per domain.

Carbon per domain

Green is good

The green sign that says green means that that domain is marked as running on green energy in the Green Web Foundation database.

We also produce a list of the top ten dirtiest assets on the page. The ones that produces most carbon emission.

Carbon per asset

Here we have one JavaScript bundle that produces 39% of the total emission for that page. I wonder what kind of cool functionality they have on the page? :)

We also slice and dice the data per content type. This is interesting because it can help you take environment friendly decisions. For example for this website, having a specific font stands for over 50% of the estimated carbon emission for that page.

Carbon per content type

Extra configuration #

By default the hosting data (knowing if a host is green) is collected from a local SQLite database included in sitespeed.io. You can use the Green Foundations API directly for the latest and fresh data using --sustainable.useGreenWebHostingAPI. That will generate a GET request to the API though.

You can also disable the hosting match (all hosts will be treated as grey hosting) with --sustainable.disableHosting.

Video and Visual Metrics on OS X #

An old friend is back, we again support video and Visual Metrics on OS X! You need to install FFMpeg and the rest of the dependencies, checkout the Travis-CI setup.

We also a aim to make it possible to use video Visual Metrics on Windows and you can help us out in Browsertime #1203!

EdgeDriver automatically installed #

If you run on an OS that supports Edge, latest EdgeDriver will be automatically installed. If you want to skip installing, use EDGEDRIVER_SKIP_DOWNLOAD=true as an environment variable.

Choose driver version #

Since the ChromeDriver team decided that a ChromeDriver version needs to match a browser version, it has been more work to test other Chrome versions.

You can download the ChromeDriver yourself from the Google repo and use --chrome.chromedriverPath to help Browsertime find it or you can choose which version to install when you install sitespeed.io with a environment variable: CHROMEDRIVER_VERSION=81.0.4044.20 npm install

You can also choose versions for Edge and Firefox with EDGEDRIVER_VERSION and GECKODRIVER_VERSION.

And more #

We also done a couple of bug fixes. Checkout the Browsertime changelog and the sitespeed.io changelog for the full list.

/Peter
